Governor

Governor
[12 دی 1391 ساعت 18:45] لوازم جانبی آرسی > Governor

گاورنر

Specifications:

  • Operating voltage:DC4.5V-6V
  • Consumption current:<20mA@4.8V
  • Direct detection of engine rotation speed.
  • Speed control range:10500~21000RPM
  • Servo RWM output pulse width: 1~2ms,not apply to S9251、S9256 and other 760μs servos.
  • Operating temperature range:-20°C~85°C
  • Operating moisture range:0%~95%
  • Case size(body):28.5x26.2x9mm
  • Signal wire length:160mm
  • Sensor wire length:250mm
  • Weight:10g(including wires)


  • Model: HE50H09
  • price:65$
