●Features

●Equipped with the low CG DFC rotor head, effectively reduce wind resistance during flight, providing the most direct and precise control feel back to the pilot, and exhibits exhilarating 3D performance and unimaginable flight speed.
●Unique carbon composite technology which effectively strengthen the weak areas and simplify electronics installation.
●Servos can be mounted directly onto frame without mounting nuts.
●Rear in-frame rudder servo mount design for centralize 3G for best 3D performance.
●Equipped with MX series high efficiency brushless motor, with heatsink style casing and embedded fan to dramatically improve cooling and increase power output.
●Unique fast release gyro and receiver mount design for fast removal and sturdy attachment.
●Uses high precision slant tooth (helical) main gear, with higher load sustainability and lower noise output.
●Brand new tail gear box with higher material quality and easy maintenance.
●High quality new tail gearbox design, combined with new dual point mounted tail pitch control assembly to minimize slops and increase rudder control precision.
●Highly efficient shaft driven tail system which effectively reduce power loss found on belt driven system, and at the same time increase performance during flight.
●Brand new 4mm carbon rudder control rod and metal rudder pitch bell crank to further improve the rudder locking effect and controllability.
●New style battery mounting platform to strengthen frame as well as provide mount for electronic speed controller.
●New style lower CG landing gear.
●Newly styled aerodynamically canopy for the ultimate fit, making the helicopter stand out.
●Best tail gear ratio to minimize vibration caused by high speed operation of main blades, bringing the best tail locking power.
●High quality new tail gearbox design, combined with new dual point mounted tail pitch control assembly to minimize slops and increase rudder control precision.

3GX Specification
●Operating Temperature:-10~60 degree
●X and Y axis Operating Angle Range:-300~+300 degree
●Z axis Operating Angle Range:-600~+600 degree
●Size:36.5x25.2x15.6 mm Size
●Weight11g Weight
●Supports Wide/Narrow Bandwidth Digital and brushless servos
●Spektrum and JR Satellite antennas support (Replaces original factory receiver)
●Futaba S.BUS system support
●Built in governor function
●Maximum working voltage:8.5V
●Compatible with 1024/2048 resolution Spektrum receivers
●Supports 90/120/135/140 CCPM swashplates
●Field setup without the use of a PC
●Compatible with 2 to 5 blades rotor heads
●Support up to 6 servos
●Automatic servo type recognization

Airframe Specification
● Length: 868mm
● Height: 275mm
● Main Blade Length: 425mm
● Main Rotor Diameter: 978mm
● Tail Rotor Diameter: 206mm
● Motor Drive Gear:12T
● Main Drive Gear:134T
● Autorotation Tail Drive Gear: 145T
● Tail Drive Gear: 36T
● Drive Gear Ratio: 1:11.17:4.03
● Weight(With Motor): 1210g

Focus Shot1(Equipped with the low CG DFC rotor head, exhibits exhilarating 3D performance and unimaginable flight speed,New 500DFC CCPM Metal Swashplate and metal main shaft bearing block)	Focus Shot2(Newly designed electronic equipments and ESC mount)		Focus Shot3(Unique carbon composite technology which effectively strengthen the weak areas and simplify electronics installation)
Focus Shot4(Uses high precision slant tooth (helical) main gear, with higher load sustainability and lower noise output.)	Focus Shot5(Newly Metal Anti Rotation Bracket)		Focus Shot6(Newly designed Gyro and Receiver mount)
Focus Shot7(Brand new carbon tail control pushrod assembly)	Focus Shot8(High efficiency shaft tail drive system,High quality new tail gearbox design, combined with new dual point mounted tail pitch control assembly )		Focus Shot9(500MX Brushless Motor(1600KV))
Focus Shot10(425 3G Carbon fiber blades)	Focus Shot11(DS515M Digital servo)		Focus Shot12(DS525M Digital servo)
Focus Shot13(RCE-BL70G Brushless ESC)
