Features

• USB-C Charging port with 2cell Battery Management. 1.5A Current Max.
• Industrial grade 4.3 inch 480*272 outdoor-readable color screen
• External UART ports to expand the capabilities of your radio.
• Supports Telemetry (Protocol and Receiver dependent)
• Memory 16M (can be expanded by Micro SD card)
• Full Speed Native TBS Crossfire support (400K)
• Full-Size High-Quality HALL sensor gimbals
• 6-Flight Mode Buttons (Pixhawk and more!)
• USB-C Simulator and PC connection port.
• Internal Multi-protocol RF System
• Three-color LED status display
• Durable Black Plastic Casing
• Vibration reminder function
• Compatible with OpenTX
• Improved JR module slot

• STM32F429BIT6 MCU

• Touch Panel Screen
• Wheel menu button
• Voice function

Specifications

• Battery: 2 x 18650 (tray supplied) or 2S lipo (batteries not included)
• Current: 400mah (excluding external module)
• External Micro SD slot: Card Included
• Battery Compartment：25*52*97mm
• 2 x External UART Expansion Ports
• Working current: 350mA@8.4V
• Weight: 750g (without battery)
• Working voltage: 5.5-18v DC
• Size: 286.9*128.9*183.8mm
• Channel: 16ch

Manuals

• TX16S Quick Start Guide
  TX16S User Manual

Firmware Updates

• TX16S Production SD
• TX16S Production Firmware

Includes

• 1x TX16S Radio (Black)
• 1x EPP Carrying Case
• 1x USB-C Cable
• 1x 18650 Tray
